Hanna Instruments HI98194 - Sensor Specifications

16
HI7698194‑0 HI7698194‑1 HI7698194‑2 HI7698194‑3
Description pH pH/ORP Dissolved Oxygen EC
Measure Type
Primary Unit
pH, mV (pH) pH, mV (pH/ORP)
D.O.
(% sat. & conc.)
EC
Measure
Range
0.00 to 13.00 pH
±600.0 mV
0.00 to 13.00 pH
±600.0 mV
±2000.0 mV
0.0 to 500.0 %
0.00 to 50.00 mg/L
0.0 to 200.0 mS/cm
0.0 to 400 mS/cm
(absolute)
Temperature
Range
‑5 to 55°C ‑5 to 55°C ‑5 to 55°C ‑5 to 55°C
Color Code Red Red White Blue
Materials
Tip: glass (pH)
Junction: ceramic
Body: PEI
Electrolyte: gel
Reference: double
Tip: glass
(pH); Pt (ORP)
Junction: ceramic
Body: PEI
Electrolyte: gel
Reference: double
Cat/An: Ag/Zn
Membrane: HDPE
Body: white top ABS
CAP
Stainless steel
electrodes AISI 316
Body: ABS/EPOXY
Maintenance
Solution
HI70300
(storage solution)
HI70300
(storage solution)
HI7042S
(D.O. electrolyte)
none
Dimensions 118 x 15 mm 118 x 15 mm 99 x 17 mm 111 x 17 mm
Depth 20 m (65’) 20 m (65’) 20 m (65’) 20 m (65’)
SENSOR SPECIFICATIONS
