Hour meter / tachometer
The display screen shows:
▪ Tachometer: Engine speed (RPM, revolutions per minute). The engine speed is measured from the cutting rotor speed
sensor and so only displays accurate speed while the cutting rotor is engaged.
▪ Hour meter (also displays minutes)
Hydraulic winch operation (optional machine feature)
Specifications
Model: Comeup HV-3
Rope type: 50m Dynice 75 or equivalent (minimum break load 4.2 ton)
Line pull: 1400 kg max
Line speed – 20m/min
Winch operation:
The winch is operated via a control panel near the base of the winch unit. The switch on the right controls whether the winch is
being extended or retracted. The switch on the left toggles between remote control and manual control (via the chipper body).
Note: You may only operate the winch while the feed roller is in the neutral position.
To disengage the winch, pull the T-handle up and twist to a horizontal position. When the winch is disengaged, the rope may be
freely pulled from the drum (free spool).
