Hansa C65RX - Page 30

Hansa C65RX O&M Manual – OM-029 First Release 4/05/2021
© Hansa Chippers 2021
28
4. Eight grease nipples on the outlet chute (two
underneath the front edge)
5. One grease nipple on the engine
engagement screw thread: Remove the
‘Engagement Guard’ to reach the grease
nipple by removing the 3 mounting bolts
6. One grease nipple for the feed roller spline
connection:
2 nipples
(one on each side)
Engagement guard
Grease nipple
