Appliance partsPage EN-12
Nozzles
The vacuum cleaner comes with
various nozzles designed for a
range of uses. Where required,
before or during vacuuming,
each nozzle can be attached
to the telescopic tube handle
on the suction hose (12) or the
telescopic tube (13).
Floor nozzle
(18)
(14)
You will work with the floor noz-
zle (14) most of the time as it is
designed for large, flat surfaces.
Best vacuuming results are
achieved when you adapt the ap-
pliance to the floor surface using
the foot selector switch (18).
(18)
– For short-pile or smooth floors
such as needle felt, PVC, par-
quet or tiles:
Set the foot selector switch to
the position.
– For long-pile rugs/carpets:
Set the foot selector switch to
the position.
The foot selector switch can also
be readjusted during operation.
Depending on the floor covering
and degree of dirtiness, you can
adjust the suction force using the
suction force control unit (1) (see
section “Setting the suction force”
on Page EN-18).
Appliance parts
