Start-up
Page EN-15
Start-up
Unpacking the
appliance
NOTICE
Risk of damage to property!
Improper handling of the ap
-
pliance may result in damage.
■ Do not use sharp objects to
unpack the appliance.
1. Unpack the appliance.
2. Carefully remove all parts of
the packaging, plastic profiles,
tape and foam padding.
Setting up the
appliance
(15)
(16)
1. Connect the suction hose (15)
and the telescopic tube (16).
(5)
(22)
2. There are two tabs on the con-
nector piece (22) on the other
end of the suction hose (15).
Insert the connector piece
into the opening of the suction
hose connector (5). To do this,
guide the two tabs into the re-
cesses in the opening of the
suction hose connector.
3. Screw-in the connector piece
by turning it clockwise.
(17)
(16)
4. Select the desired nozzle, e.g.
the floor nozzle (17) and insert
it into the telescopic tube (16).
You can also insert all nozzles
directly into the telescopic
tube handle (15) located on
the suction hose.
