VI-EQ/3 M. S. - 0012
ADDIIONA
TECHNICAL SPECIFICATION AND INPUT CONNECTIONS
Using a microprocessor allows us to memorize and correctly restore the geometry without using a potentiometer.
Image adjustment is made with the control panel that activates an "On-Screen Display" in order to access,
modify and memorize all the parameters.
Color system: Standard: PAL – SECAM – NTSC 4.43 and 3.58 automatic selection.
Standard signals: CCIR 625 lines/50Hz – EIA 525 lines/60Hz
Passing video bandwidth: Video composite: 6Mhz (-3 dB) – RGB 8 MHz (-3dB) – SVHS 8Mhz (-3 dB)
Operating temperature: from +5 to +40°C
Standard PAL and NTSC 3.58 Comb Filter.
C.T.I. (Color Transient Improvement) to improve the color reproduction quality.
Possibility to give the image a "sharpness" effect called "Peaking".
Audio output power: 8W at 8 ohm.
Automatic degaussing each time the monitor is turned on.
Possibility to adjust the color also in RGB input.
Extra beam current circuit protection for the CRT and Extra High Voltage (X-ray protection).
Vertical refresh: 1,1 ms
Horizontal refresh: 10,7
µ
s
OPTIONAL CIRCUIT ACCESSORIES
Stereo module–output power = 2 x 8 W
Timed degauss module from 1 to 12 hours.
AVAILABLE VERSIONS
All the models of the –EQ3 range are available in two versions:
Rear control version
Front control version
In the front control version, the analog, 5-button control panel shown in point 1 in the previous photo is on
the lower front part of the monitor.
The functions of the individual key remain the same
TECHNICAL SPECIFICATION
.2
