Hantarex EQ/3 User Manual

VI-EQ/3 M. S. - 0012
SPARE PARTS
62004730 Local keyboard module
34076570 Connector 6 way
50430850 Touch Switch 90ø
62005490 Mains filter and Degauss module
20180040 Red Led diode 3mm LD1
20400429 Transistor BC 547 B T1
20620320 I.C. MAC 8N TRIAL D1
20620330 I.C. TLP 3063/D4-LF2 IC1
21000140 PTC 22R 15A PTC1
28020470 Mains filter 2x40 mH TH1
34073410 3 ways Male connector CN2
34076561 3 ways connector CN1
62005610 Socket module EQ/3 VER. B
20100012 Diodo BA 159 D1-4-7-8
20420159 Transistor BF 423/BF 421 T2-7-11-14
20420219 Transistor BF 422-BF 422 L/RA T4-6-12-15
20420500 Transistor BF 871 T5-9-13
21332201 Non flamable resistor 1/2W 5% 220R R3
34020400 Terminator SP2
34020640 Zoccolo CRT Small-Neck
34070100 Connector 9 way CN2
34076565 Connector 6 way CN1
20110046 SMD diode SOT 23 BAS 16 D2-3-5-6-9-10-12
20300003 SMD transistor SOT 23 BC 857B T1-3-8-10
62005440 IR Receiver module EQ/3
20676151 Ricevitore infrarosso
21291509 SMD resistor 0805 5% 150R
62005410 Deflection module EQ/3
21000120 Zener diode 33V 1W D8
21000340 NTC 8/10R 20% R17
21225600 Resistor 1/4W 5% 56R R10
28025510 Linearity coil L11
28027470 Bridge coil L12
28028500 EHT Transformer V.I. TH2
29100018 Fuse 2AT 5x20mm
30000801 Switch
20100020 Zener diode 24V 1W 5% D20
20110141 Zener diode 47V 1/2W 5%
20150131 Diodo BY 255 D6-7-9-10
20150171 Diodo BYV 95/C - BYW 36 D16
20150210 Diodo BY 228 D34
20150230 Diodo BYW 95C/A52R-600 D12-13-15-33
20410210 Transistor BD 682 TR4
20430322 Transistor BU 508 AF TR5 (PH)
20430323 Transistor BU 508 AFI TR1 (SGS)
20670030 I.C. TDA 4601 IC1
20673510 I.C. TDA 8143 IC3
21321001 Non flamable resistor 1/2W 5% 10R R50
21332209 Non flamable resistor 1/2W 22R R45
23044700 Trimmer 4K7 RV1
28021150 Chocke 150uH L18
28021190 Chocke 50uH L13
28060640 Chocke coil L4
28070510 Switch transformer V.I. TH1
34023356 6 way Connector CN3
34074640 2 way Connector CN1
34076561 3 way Connector CN2
34076563 4 way Connector CN5
20100012 BA 159 diode D4-5
20150008 1N 4007 diode D1-2-18
28027360 Chocke coil 22uH 10% L17
28060480 Chocke coil 3u9 10% L2
SPARE PARTS
4
