Hantarex EQ/3 User Manual

VI-EQ/3 M. S. - 0012
62004680 Signal module V.I./3
20110021 Zener diode 6V2 1/2W D17
20110030 Zener diode 3V6 0,5W D21
20110070 Zener diode 4V7 1/2W 5% D14
20150460 Diode BYD 33 G/M D18
20180040 Red Led diode 3mm LD1
20410110 Transistor BDX 54 B T35
20620040 I.C. TL 7705 ACP IC14
20620041 I.C. MM 74 HC 4066 N IC6
20620070 I.C. L 7805 CV IC7-8
20620080 I.C. L 7812 CV IC10
20620086 I.C. L 7912 CV IC11
20620120 I.C. 74 HC 4053 IC5
20620130 I.C. 24 LC 04 B/P IC15
20620160 I.C. TDA 4671 PSI IC4
20620560 I.C. MTV 004 N/EN IC18
20620980 I.C. TDA 8358 IC2
20620990 I.C. TDA 8844 IC1
20621010 I.C. TDA 9181 P/N1 IC3
20621110 I.C. 87 C 54 IC12
20640150 I.C. LM 7808 IC9
20640170 I.C. MM 74 HC 14 N IC13
21304701 Non flamable resistor 1/2W 5% R47 R147
21331002 Non flamable resistor 1/2W 5% 100R R64
21536800 Non flamable resistor 2W 5% 68R R141
28020640 Chocke coil 100uH 10% L6
28020720 Chocke coil 47uH 10% L7-10
28027360 Chocke coil 22uH 10% L3-5-4-9
28027781 Chocke coil 220uH 10% L1-2
28060480 Chocke coil 3u9 10% L8
29030320 Quartz 11.0592 MHZ XT4
29700090 Quartz 3,579545 MHz XT1
29700140 Quartz 4.433619 MHZ XT3
34023352 2 way Connector CN4
34040164 RCA connector PR2
34040330 4 wire MINI DIN connector PR1
34070100 9 way Connector CN6-7
34073691 SCART connector PR6
34074823 3 way Connector CN8
34076550 8 way Connector CN1-3
34076561 3 way Connector CN5
34076563 4 way Connector CN10
34076565 6 way Connector CN9-14
34076568 12 way Connector CN2
34076950 PCB Connector PR5
34077400 Connector BNC PR3-4
20110045 SMD diode BAV 99 D1-2-4-5-6-7-9-11-12-13-15-16-19-24-26-27-28-29-30-31-32-33-34-8
20110046 SMD diode SOT 23 BAS 16 D3-10-20-22-25-38
20110047 SMD diode SOT 23 BAT 54 D35-36-37-39
20300002 SMD transistor SOT 23 BC 847B T1-2-6-7-9-10-11-12-13-19-21-22-23-24
20300003 SMD transistor SOT 23 BC 857B T3-4-5-8-17-18-20
20400140 SMD transistor SOT 23 BCV 27 T33
SPARE PARTS
44
.1
