Hantek DSO2D15 User Manual

71 / 72
Persist
1s, 5s, 10s, 30s, infinite
Interface
Standard interface
USB Host, USB Device
Power Supply
Supply Voltage
100-120VAC
RMS
(±10%), 45Hz to 440Hz, CATⅡ
120-240VAC
RMS
(±10%), 45Hz to 66Hz, CATⅡ
Power Consumption
<15W
Fuse
T2A 250VAC 4*8
Environmental
Operating Temperature
0 to 50 °C (32 to 122 °F)
Storage Temperature
-40 to +71 °C (-40 to 159.8 °F)
Humidity
≤+104℉(≤+40℃): ≤90% relative humidity
106℉~122℉ (+41℃ ~50℃): ≤60% relative humidity
Cooling Method
Convection
Altitude
Operating and Nonoperating
3,000m (10,000 feet)
Random Vibration
0.31g
RMS
from 50Hz to 500Hz, 10 minutes on each axis
Nonoperating
2.46g
RMS
from 5Hz to 500Hz, 10 minutes on each axis
Mechanical Shock
Operating
50g, 11ms, half sine
Mechanical
Dimension
318 x 110 x 150mm (L x W x H)
Weight
1900g
Appendix B: Accessories
All the following accessories are available by contacting your local HANTEK distributor.
Standard Accessories
⚫ A Passive Probe (1.5m, 10:1)
⚫ A Test Lead with two clips
⚫ A Power Line
⚫ A USB Line
⚫ A BNC to BNC (Only for the scopes with waveform generator function)
⚫ A PC Software CD of the oscilloscope
⚫ Warranty Card
⚫ Manufacturer Certificate
⚫ Certificate Of Calibration

Hantek DSO2D15 Specifications

General

Bandwidth	150 MHz
Channels	2
Sample Rate	1 GSa/s
Memory Depth	8 Mpts
Vertical Resolution	8 bits
FFT	Yes
Digital Voltmeter	Yes
Frequency Counter	Yes
Trigger Modes	Edge, Pulse, Video, Slope, Alternate
Display	7 inch TFT LCD
Vertical Sensitivity	2 mV/div ~ 10 V/div
Waveform Generator	25 MHz
Input Impedance	1 MΩ ± 2%
Interface	USB Host, USB Device
