Hanwell IM6001 - Connecting SR2 Power Supply and Network Link

Hanwell Smart Receiver 2 (SR2)
Instruction Manual
IM6001 - 3 Page 10 of 22
hanwell.com
4.3 Connecting the Power and Network
WARNING!
To Avoid Possible Electric Shock or Personal Injury, Follow These Guidelines:
DO NOT operate this Unit without a properly grounded, properly polarised power cord.
DO NOT connect this Unit to a non-grounded, non-polarised outlet.
1.
Unscrew the front panel (top screw) and lower the front.
2.
Check that fuses F1, F2 and F5 are fitted (circled in green in Figure 5 above).
3.
Check that the coin cell is fitted (with the positive side topmost).
4.
Remove the UPS battery from the Unit’s packaging and fit it into the SR2 Unit.
5.
Connect the UPS battery to the leads.
Caution:
Double-Check the Polarity!
6.
Close the front panel and screw it into place.
7.
Select the correct local Mains voltage using the Voltage Selection switch on the
underside of the Unit (115 or 240 Volts); see Figure 2 above.
Note: The SR2 Unit is supplied set to 240 Volts.
8.
Slide back the locking mechanism on the top of the plug to release the friction lock (see
Figure 3 on page 5) and insert the IEC Power Cord Plug into the IEC Socket on the
underside of Unit.
Note: You must also slide back the locking mechanism on the top of the plug to release
the friction lock when removing the IEC Power Cord.
9.
Release the locking mechanism and pull down on the IEC Power Cable Plug to check
that it is locked in place and cannot become detached.
10.
Connect the mains power and switch on.
11.
Confirm that the Mains LED comes on.
12.
Confirm that the Receiver LED comes on.
13.
Connect the LAN cable from the LAN socket on the SR2 to the enabled Ethernet socket.
14.
Confirm that the Network Link LED comes on.
