6.2 MS1000 Control Panel
The SR2 can be connected to a Hanwell MS1000 Control Interface. See the Online User
Guide:
http://www.help.emsprocloud.com/index.html?bms-control.html
The MS1000 Unit should be connected to JP12 (See Appendix 1 – SR2 Connection Data) as
follows:
Pin Connection
1 12V OUT
2 TX +
3 TX -
4 GND
6.3 On Board Sensors
The SR2 has 8 inputs for local probes, the equivalent of 4 x RL2000 Sensors with pre-defined
ID numbers.
The probes should be connected to JP13 (See Appendix 1 – SR2 Connection Data), as follows:
Radio Sensor Type EMS ID No. Channel Probe Connections
RL2000 Dual
Thermistor
200
Thermistor A
Pin 1: positive
Pin 2: GND
Thermistor B
Pin 3: positive
Pin 4: GND
RL2000
RH/Thermistor
201
RH
Pin 5: +5V
Pin 6: signal
Pin 8:GND
Thermistor
Pin 7: positive
Pin8: GND
RL2000 Linear 202
Linear
4 to 20mA
Pin 9: positive
Pin 10: negative
Linear
4 to 20mA
Pin 11: positive
Pin 12: negative
RL2000 203
Digital
Pin 13: positive
Pin 14: negative
Digital
Pin 15: positive
Pin 16: negative
