Hanwell Smart Receiver 2 (SR2)
Instruction Manual
hanwell.com
Page 5 of 22 IM6001 - 3
2.3 SR2 Receiver Unit – External Appearance
Figure 1 - SR2 Unit Control Panel
Figure 2 - Underside of Unit
Figure 3 - IEC Power Cord with Locking Mechanism
Locking Mechanism*
Internal Power Supply Unit (PSU) Fuse
*Note: The SR2 MUST NOT
be powered via a
standard IEC Power
Cord without a
locking mechanism.
