24
Name Description Condition Initial valueSignal
ALARM GROUP SETTING
1
2
1
EUS(0.5 %)
EU(100.0 %)
EU(0.0 %)
EU(100.0 %)
Always
Always
Always
Set alarm mode
OFF / 1 ~ 22
Refer to “Alarm type and code”
EUS ( 0.0 ~ 100.0 % )
PV alarm, Deviation alarm
EU ( -100.0 ~ 100.0 % )
Alarm group
Type of Alarm 1
Type of Alarm 2
Type of Alarm 3
Dead band of Alarm 1
Dead band of Alarm 2
Dead band of Alarm 3
Set value of Alarm 1
Set value of Alarm 2
Set value of Alarm 3
There are 3 alarm outputs available per conrtoller. In Alarm Group, setting are made for mode,
dead band, and value of each alarm. Refer to the next page for the 19 different types of alarm
functions.
:
In Heating Cooling type of PX7, is not indicated when selecting 10,11,12
:
In PX7, is not indicated because of no third alarm output.
In Heating
Cooling type of PX3, PX2, PX9, is not indicated when selecting 10, 11, 12
18
Reference : Display lamp will be OFF when output ON in inverted type.
Without hold function, Low limit alarm will be ON when increasing temperature. (Picture 1)
SV
(low limit
alarm)
Power ON
Alarm
output
ON OFF ON OFF
PV
(Picture 1)
SV
(low limit
alarm)
Power ON
OFF OFF ON OFF
PV
(Picture 2)
Hold function : None
Hold function
Alarm
output
To Next Page
