This fan can be mounted as a flushmount on a
regular (no-slope) ceiling only.
Check to make sure blades (G) will be at least
30 in. from any obstruction and at least 7 ft. above
the floor.
7
2.
Remove all mounting bracket nuts (S) and
mounting bracket flat washers (Q) from mounting
bracket (A).
3.
INITIAL INSTALLATION
3
A
S
Q
2
7 ft.
min.
30 in.
min.
G
Secure mounting bracket (A) to outlet box (not
included) using screws, spring washers and flat
washers provided with the outlet box.
NOTE: It is very important you use the proper
hardware when installing the mounting bracket
(A) as this will support the fan.
4.
4
A
