6
Lowes.com/harborbreeze
INITIAL ASSEMBLY INSTRUCTIONS
1. Turn off the electricity at the main fuse box before
assembly.
DANGER: Failure to disconnect the power supply
prior to installation may result in serious injury or death.
ON
ON
ON
ON
ON
ON
ON
ON
1
2. Separate the ceiling bracket (G) from the motor
assembly (A) by loosening the two ceiling bracket
screws (BB) in the slotted holes, then removing the
two remaining ceiling bracket screws (BB) in the
motor assembly (A). Retain the screws for later.
Hardware Used
BB
Ceiling Bracket
Screw
x 4
A
G
BB
2
3. If not done already, secure a metal octagonal outlet
box (not included) directly to the building structure.
Note: Supply wires omitted for clarity.
3
To Next Page
