HARDI

FOAM MARKER STANDARD VERSION

6.4 Commander plus 750, 1200 & Twin Force

1. Line up the left edge of the

tank mounting bracket with

the left edge of the platform

and drill three 7/16" dia.

holes as shown in (Fig. 12).

2. Drill middle hole ﬁ rst and

then use the tank mounting

bracket as a template for the

remaining two holes.

3. Install and tighten all bolts.

Fig. 12

3-3/4" (95mm)

TAN K

FRAME

HOLES
