Page 23 of 87
Extended Menu 8 Settings
E8.1
Regulation
E8.1.1
Min. duty cycle
[2%]
Minimum and default is 2%.
Increase value if motor hesitates to turn.
For LookAhead, set to 5% +/- 1%.
See “Description 2 Min. duty cycle” on page
28
E8.1.2
Min. speed
[0.5 km/h]
Minimum speed required before regulation
valve will operate. Default is 0.5 km/h.
E8.1.3
Min. pressure
[0.0 Bar]
Default is 0.0 Bar. At 0.0 Bar, feature is
disabled. Pressure transducer needed.
If pressure drops below the set value, the
pressure regulation will stop.
E8.1.4
Valve test
[Start test? Yes, No]
This tests the regulation valve with position
feedback. Valve must not be at max. setting.
Valve will increase 2 turns and then
decrease 2 turns.
E8.1.5
Look Ahead [Yes, No] See “LookAhead” on page 34
Default = No. Regulation valve must have
position feedback transducer and Boom
sensor must be fitted.
E8
Settings
E8.1.6
Regulation delay
[0 to 9 sec]
Default = 3 seconds.
This is time the regulation valve waits before
starting.
Delay allows fluid system to stabilise before
regulation valve starts operation.
For few boom sections and or big liquid flow,
3 s is recommended.
For many boom sections and or small liquid
flow, 1 or 2 s is recommended.
E8.1.7
Sensor
E.8.1.7.1
Pressure
[Active, Passive]
Default = Passive
E.8.1.7.2
Rpm
[Future use]
E8.2
Tank
E8.2.1
Tank size
[L]
Default is 1000
Value set if a TankGauge is not fitted.
Maximum fill:
CM 3200=3500
CM 4400=4900
CM 6600=7000
NAV 3000=3300
NAV 4000=4400
E8.2.2
(Future use)
E8.2.3
Data points
[0000]
Calibration values for HARDI TankGauge.
Can be edited by use of Navigation and
Enter keys.
