Hardi MASTER TWIN STREAM User Manual

GB 04 02 MA
Description
FF
FF
F
ilterilter
ilterilter
ilter
s (optional equipment)s (optional equipment)
s (optional equipment)s (optional equipment)
s (optional equipment)
With the self-cleaning filter the impurities that exist in the
spray liquid will by-pass the filter and be recirculated
back to the tank via the return flow.
Also suction filter and nozzle filters are standard. In-line
pressure filters can be fitted as option (J).
SafSaf
SafSaf
Saf
ety locety loc
ety locety loc
ety loc
kk
kk
k
er (optional equipment)er (optional equipment)
er (optional equipment)er (optional equipment)
er (optional equipment)
A safety locker (K) can be mounted underneath the
footboard for the storage of safety gear.
BoomBoom
BoomBoom
Boom
The sprayer is fitted with TWIN STREAM (MA-HAL)
boom. The boom are supported by a trapeze which is
fitted to the tank frame.
The trapeze helps the boom to stay horizontal when
unfolded and it protects the boom against vibrations and
shocks when driving on uneven ground. This ensures
longer boom life and improves boom stability for better
spray distribution.
Booms are available in 12 and 15 m working width for
the TWIN STREAM model. All booms are provided with
spring loaded breakaway.
IdentifIdentif
IdentifIdentif
Identif
icaica
icaica
ica
tion plation pla
tion plation pla
tion pla
testes
testes
tes
An identification plate fitted on the frame indicates
producer name, model, own weight, max height, max
pressure of the hydraulic system and max pressure of
the spray liquid system. Frame, boom centre frame and
inner/outer sections also have identification plates
indicating boom type and part number. If ordering spare
parts, inform your dealer of these numbers.
SprSpr
SprSpr
Spr
aa
aa
a
yy
yy
y
er useer use
er useer use
er use
The HARDI MASTER sprayer is for the application of
crop protection chemicals and liquid fertilisers.
The equipment must only be used for this purpose. It is
not allowable to use the sprayer for other purposes.
If no local law demands that the operator must be
certified to use spray equipment, it is strongly recom-
mended to be trained in correct plant protection and in
safe handling of plant protection chemicals to avoid
unnecessary risk for persons and the environment when
doing your spray job.
T102-0018
K
T102-0017
J
