3 - Description
3.10
Equipment
Platform
The platform (A) is accessible via the step (B) located on the left side of
the sprayer frame. The platform gives access to the clean water tank lid,
the main tank lid and the optional foam marker tank lid (not shown).
Jobcom (optional)
The optional Jobcom box is located at the front of the platform.
Tank level indicator
The actual tank level in the main tank can be observed on the tank level
indicator. The scale is displayed in US gallons or Liters.
ATTENTION! This tank level indicator displays the approximate
tank contents. For more accurate tank contents, a fill-meter must
be used.
Remote pressure gauge
The remote system pressure gauge is located above the manifold valve
on the platform. This gauge measures the system pressure near the
boom distribution valves.
