8.1
8 - Technical specifications
Dimensions
Overall dimensions
All measurements are in feet and inches.
Tank capacities
Weight
Ranger 2000 (550 Gal.):
Wheel and axle dimensions
*under axle
Ranger 2000 (550 Gal.) SPB Boom
A - Total length 17’ 2”
B - Total width 10’ 0”
C - Total height 9’ 4”
Main tank capacity 550 gallons (2000 Liters)
Clean water tank capacity 5 gallons (20 Liters)
Flush tank capacity 63 gallons (240 Liters)
Foam marker tank capacity 15 gallons (57 Liters)
Total Drawbar Axle Per tire
Unfolded empty 1574 39 1535 768
Folded empty 1574 163 1411 705
Unfolded full (water) 4449 831 3618 1809
Folded full (water) 4449 955 3494 1747
All measurements are approximate - in pounds (lbs)
Wheel Min. track width Max. track width Clearance*
11.2 x 38” 60” (1520 mm) 90” (2250 mm) 28” (710 mm)
