harman/kardon AVR132/230
MAIN PCB (CUP11911Z)
Ref# Component Description Description 2 Qty
Q872 HVT2SA1360O T.R 2SA1360O 1
Q874 HVT2SA1360O T.R 2SA1360O 1
Q875 HVT2SA1360O T.R 2SA1360O 1
Q881 HVT2SC3423O T.R 2SC3423O 1
Q882 HVT2SC3423O T.R 2SC3423O 1
Q883 HVT2SC3423O T.R 2SC3423O 1
Q884 HVT2SC3423O T.R 2SC3423O 1
Q885 HVT2SC3423O T.R 2SC3423O 1
RY94 HSL1A008ZE RELAY SDT-S-112DMR 1
R656 CRF5EKR27HX2K RES , CEMENT 0.27ohm X 2 1
R657 CRF5EKR27HX2K RES , CEMENT 0.27ohm X 2 1
R658 CRF5EKR27HX2K RES , CEMENT 0.27ohm X 2 1
R659 CRF5EKR27HX2K RES , CEMENT 0.27ohm X 2 1
R660 CRF5EKR27HX2K RES , CEMENT 0.27ohm X 2 1
R905 CRG1ANJ100H
RES , METAL OXIDE
FILM
10 OHM 1W J 1
R990 CRG1ANJ100H
RES , METAL OXIDE
FILM
10 OHM 1W J 1
R993 CRG1ANJ100H
RES , METAL OXIDE
FILM
10 OHM 1W J 1
R995 CRG1ANJ100H
RES , METAL OXIDE
FILM
10 OHM 1W J 1
R997 CRG1ANJ100H
RES , METAL OXIDE
FILM
10 OHM 1W J 1
R999 CRG1ANJ100H
RES , METAL OXIDE
FILM
10 OHM 1W J 1
TH91 KRTP42T7D330B
THERMAL SENSOR ,
POSISTOR
P42T7D330BW20 1
T902 CLT5J033YE TRANS , SUB 1
POWER TRANS PCB (CUP11916-3,4)
Ref# Component Description Description 2 Qty
CUP11916-3,4 PCB , POWER TRANS PCB 1
BN96 CWB1C909150BM WIRE ASS'Y WIRE 1
BN99 CWB1B908270EN WIRE ASS'Y WIRE 1
C104 HCBS1H103ZFT CAP , CERAMIC 0.01UF 50V 1
C105 HCBS1H103ZFT CAP , CERAMIC 0.01UF 50V 1
C106 CCFT1H104ZF
CAP ,
SEMICONDUCTOR
0.1UF 50V ZF 1
C107 HCBS1H103ZFT CAP , CERAMIC 0.01UF 50V 1
C108 HCBS1H103ZFT CAP , CERAMIC 0.01UF 50V 1
Harman Consumer Group International

Harman Kardon AVR 132 Specifications

General

Number of Channels	5.1
Frequency Response	10Hz - 100kHz
Dolby Digital	Yes
DTS	Yes
Input Sensitivity	200mV
Total Harmonic Distortion	0.07%
Stereo Mode Power	50 watts per channel (8 ohms, 20Hz - 20kHz, 0.07% THD)
Input Impedance	47 kΩ
Audio Decoders	Dolby Digital, DTS
Video Inputs	Composite, S-Video
Video Outputs	Composite, S-Video
Surround Mode Power	50 watts per channel (8 ohms, 20Hz - 20kHz, 0.07% THD)
