Harman Kardon AVR 132 Service Manual

harman/kardon AVR132/230
INPUT PCB (CUP11931-1)
Ref# Component Description Description 2 Qty
Q302 HVTKTC2874BT T.R , MUTE KTC2874B 1
Q303 HVTKTC2874BT T.R , MUTE KTC2874B 1
Q304 HVTKTC2874BT T.R , MUTE KTC2874B 1
Q305 HVTKTC2874BT T.R , MUTE KTC2874B 1
Q306 HVTKTC2874BT T.R , MUTE KTC2874B 1
Q311 HVTKTC2874BT T.R , MUTE KTC2874B 1
CN10 CJP04GB46ZY WAFER WAFER 1
CN11 CJP13GA117ZY WAFER , CARD CABLE WAFER 1
CN12 CJP21GA115ZY WAFER , CARD CABLE WAFER 1
CN13 CJP13GA115ZY WAFER , CARD CABLE WAFER 1
CN14 CJP09GA117ZY WAFER WAFER 1
CN17 KJP12GB142ZP PIN HEADER WAFER 1
CN18 CJP05GA19ZY
WAFER, STRAIGHT,
5PIN
WAFER 1
CN19 CJP09GA117ZY WAFER WAFER 1
CN20 CJP05GA01ZY
CON WAFER YMW025-
05R
WAFER 1
CN22 CJP06GA19ZY
WAFER, STRAIGHT,
6PIN
WAFER 1
CN72 CJP17GA117ZY WAFER WAFER 1
C732 CCEA0JKR3222E CAP , ELECT 2200UF 6.3V 1
IC36 HVIL7808CP I.C , REGULATOR (+8V) ST 1
IC37 HVINJM7908FA I.C REGULATOR JRC 1
JK11 CJJ4R019W TERMINAL , IN/OUT TERMINAL JACK 1
JK12 CJJ4P014W JACK , IN/OUT TERMINAL JACK 1
JK13 CJJ4R019W TERMINAL , IN/OUT TERMINAL JACK 1
JK14 CJJ4P043W JACK IN/OUT JACK 1
R712 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
R732 CRD20TJ103T RES , CARBON 10K OHM 1/5W J 1
X701 HOX24576E150TF CRYSTAL 24.576MHZ 1
RDS PCB (CUP11931-2)
Ref# Component Description Description 2 Qty
CUP11931-2 PCB , RDS PCB 1
C709 CCUS1H102KC CAP , CHIP 1000PF 1
C711 CCUS1H102KC CAP , CHIP 1000PF 1
C712 CCUS1H223KC CAP , CHIP 0.022UF 1
C713 CCUS1H390JA CAP , CHIP 39PF 1
C714 CCUS1H390JA CAP , CHIP 39PF 1
Harman Consumer Group International

Harman Kardon AVR 132 Specifications

General

Number of Channels	5.1
Frequency Response	10Hz - 100kHz
Dolby Digital	Yes
DTS	Yes
Input Sensitivity	200mV
Total Harmonic Distortion	0.07%
Stereo Mode Power	50 watts per channel (8 ohms, 20Hz - 20kHz, 0.07% THD)
Input Impedance	47 kΩ
Audio Decoders	Dolby Digital, DTS
Video Inputs	Composite, S-Video
Video Outputs	Composite, S-Video
Surround Mode Power	50 watts per channel (8 ohms, 20Hz - 20kHz, 0.07% THD)
