Surround Mode Description Incoming Bitstream or Signal
Virtual speaker Simulates 5.1 channels when only two speakers are present or a more enveloping
sound field is desired.
Ř'ROE\'LJLWDO
Ř$QDORJWZRFKDQQHO
Ř7XQHU
Ř3&0N+]N+]RUN+]
DTS Digital Using a different encoding/decoding method than Dolby Digital,
DTS Digital also provides up to five discrete main channels, plus an
LFE channel.
Ř'76RURURURURU
3/2/.0 or .1
Ř'76(60DWUL[SOD\HGDV
Ř'76(6'LVFUHWHSOD\HGDV
DTS-HD DTS-HD is a new high-definition audio format that complements the high-definition
video found on Blu-ray Disc and HD-DVD discs. It is transmitted using a DTS core
with high-resolution extensions. Even when only DTS 5.1 surround sound is desired
(or available, if the multizone system is in use), the higher capacity of high-resolution
discs serves up DTS at twice the bit rate used on DVD-Video discs.
Ř%OXUD\'LVFRU+''9'GLVFVHQFRGHGZLWK'76+'PRGHV
delivered via HDMI connection
DTS-HD Master Audio DTS-HD Master Audio technology delivers bit-for-bit reproductions of the studio
master recording in up to 7.1 channels for an incredibly accurate performance.
Ř%OXUD\'LVFRU+''9'GLVFVHQFRGHGZLWK'76+'0DVWHU$XGLR
technology, delivered via HDMI connection
DTS-ES Matrix DTS Extended Surround adds a single surround back channel to DTS 5.1 digital
surround sound. The Matrix version includes the surround back channel information
“matrixed” into the left and right (side) surround channels for compatibility with 5.1-
channel systems.
Ř'76(60DWUL[
DTS-ES Discrete DTS-ES Discrete is another Extended Surround mode that adds a surround back
channel, but this information is encoded discretely on the disc and is not derived
from information contained in the surround channels.
Ř'76(6'LVFUHWH
DTS Stereo Delivers a two-channel downmix of DTS Digital materials or presents a matrix-
encoded surround presentation.
Ř'76RURURURURU
3/2/.0 or .1
Ř'76
Ř'76(60DWUL[
Ř'76(6'LVFUHWH
Table A8 – Surround Modes – continued

Harman Kardon AVR 1510 Specifications

Audio Specifications

stereo power	75W per channel, two channels driven @ 6/8 ohms, 1kHz, <0.1% THD
multichannel power	75W per channel, two channels driven @ 6/8 ohms, 1kHz, <0.1% THD
input sensitivity/impedance	250mV/27k ohms
signal-to-noise ratio (IHF-A)	75dB
frequency response (@ 1W)	10Hz – 130kHz (+0dB/–3dB)
high instantaneous current capability (HCC)	±25 amps
slew rate	40V/sec

FM Tuner Specifications

frequency range	87.5MHz – 108.0MHz
usable sensitivity IHF	1.3µV/13.2dBf
signal-to-noise ratio (mono/stereo)	70dB/68dB
distortion (mono/stereo)	0.2%/0.3%
stereo separation	40dB @ 1kHz
selectivity (±400kHz)	70dB

AM Tuner Specifications

frequency range	520kHz – 1, 510kHz
signal-to-noise ratio	38dB
usable sensitivity (loop)	375µV
distortion (1kHz, 50% mod)	1.0%
selectivity (±10kHz)	30dB

Video Specifications

television format	NTSC
input level/impedance	1Vp-p/75 ohms
output level/impedance	1Vp-p/75 ohms
video frequency response (composite video)	10Hz – 8MHz (–3dB)
HDMI	Supports up to 4K x 2K

General Specifications

power requirement	120V AC / 60Hz
power consumption	<0.5W (standby); 410W maximum
dimensions (H x W x D)	4-3/4" x 17-5/16" x 11-13/16" (121mm x 440mm x 300mm)
weight	10 lb (4.6kg)
