AVR 1565/AVR 1566 Specifications
Specifications
Audio Section
Stereo power: 70W per channel, two
channels driven @ 8
ohms, 1kHz, <0.9%
THD
Multichannel power: 70W per channel, two
channels driven @ 8
ohms, 1kHz, <0.9%
THD
Input sensitivity/impedance: 200mV/47k ohms
Signal-to-noise ratio (IHF-A): 100dB
Surround system adjacent-channel separation: Dolby Pro Logic/PLII:
40dB
Dolby Digital: 55dB
DTS: 55dB
Frequency response (@1W): 10Hz – 130kHz
(+0dB/–3dB)
High instantaneous-current capability (HCC): ±25 amps
Transient intermodulation distortion (TIM): Unmeasurable
Slew rate: 40V/μsec
FM Tuner Section
Frequency range: 87.5 – 108.0MHz
Usable sensitivity IHF: 1.3μV/13.2dBf
Signal-to-noise ratio (mono/stereo): 70dB/68dB
Distortion (mono/stereo): 0.2%/0.3%
Stereo separation: 40dB @ 1kHz
Selectivity (±400kHz): 70dB
Image rejection: 80dB
IF rejection: 90dB
AM Tuner Section
Frequency range: 520 – 1720kHz
Signal-to-noise ratio: 45dB
Usable sensitivity (loop): 500μV
Distortion (1kHz, 50% mod): 0.8%
Selectivity (±10kHz): 30dB
Video Section
Television format: NTSC
Input level/impedance: 1Vp-p/75 ohms
Output level/impedance: 1Vp-p/75 ohms
Video frequency response (composite video): 10Hz – 8MHz (–3dB)
HDMI: Version 1.4a with 12-bit
Deep Color
General Specifications
Power requirement: 120V AC/60Hz
Power consumption: <0.5W (standby);
280W maximum
Dimensions (W x H x D) 17-5/16" x 6-1/2" x 17-1/8"
(440mm x 165mm x 435mm)
Weight 20 lb (9.1kg)
