4
AVR 1565/AVR 1566 Front-Panel Controls
Front-Panel Controls
Power
Indicator
Message
Display
Volume
Knob
Surround Mode
Select Buttons
Set
Button
IR
Sensor
Power
Button
Left/Right
Buttons
Headphone Jack
Source Select
Buttons
Tuning Mode
Button
Digital Input
Button
Surround-Mode
Category Button
Up/Down Buttons/
Tuning Buttons
USB
Port
Aux Analog
Audio Input
Connector
Channel
Level Control
Button

Table of Contents

Other manuals for Harman Kardon AVR 1565

Preview: Specifications
Specifications2 pages
Preview: Quick Start Guide
Quick Start Guide8 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Harman Kardon AVR 1565 and is the answer not in the manual?

Harman Kardon AVR 1565 Specifications

General IconGeneral
Impedance75 Ω
Receiver type-
Frequency range10 - 130000 Hz
Audio output channels- channels
Signal-to-Noise Ratio (SNR)45 dB
Power output per channel (1KHz@8 Ohm)70 W
Power output per channel (20-20KHz@8 Ohm)- W
HDMI in3
Number of HDMI outputs1
Ethernet LANNo
AM band range520 - 1720 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
3DYes
Analog signal format systemNTSC
HDMI version1.4a
Product colorBlack, Grey
Volume controlRotary
Weight and Dimensions IconWeight and Dimensions
Depth435 mm
Width440 mm
Height165 mm
Weight4127 g
