Harman Kardon AVR 1600 User Manual

51
AVR 1600 TECHNICAL SPECIFICATIONS
Audio Section
3TEREO -ODE #ONTINUOUS !VERAGE 0OWER &4#
50 Watts per channel, 20Hz–20kHz, @ <0.07% THD,
both channels driven into 8 ohms
3EVEN#HANNEL 3URROUND -ODES
Power per Individual Channel
Front L & R channels:
50 Watts per channel
@ <0.07% THD, 20Hz–20kHz into 8 ohms
Center channel:
50 Watts @ <0.07% THD, 20Hz–20kHz into 8 ohms
Surround (L & R Side, L & R Back) channels:
50 Watts per channel
@ <0.07% THD, 20Hz–20kHz into 8 ohms
Input Sensitivity/Impedance
Linear (High-Level) 200mV/47k ohms
Signal-to-Noise Ratio (IHF-A) 100dB
Surround System Adjacent Channel Separation
Pro Logic
®
I/II 40dB
Dolby
®
Digital (AC-3) 55dB
DTS
®
55dB
Frequency Response
@ 1W (+0dB, –3dB) 10Hz – 130kHz
High Instantaneous
Current Capability (HCC) ±25 Amps
Transient Intermodulation
$ISTORTION 4)- 5NMEASURABLE
Slew Rate 40V/μsec
FM Tuner Section
&REQUENCY 2ANGE n-(Z
Usable Sensitivity IHF 1.3μV/13.2dBf
3IGNALTO.OISE 2ATIO -ONO3TEREO D"
$ISTORTION -ONO3TEREO 
Stereo Separation 40dB @ 1kHz
Selectivity ±400kHz, 70dB
Image Rejection 80dB
IF Rejection 90dB
AM Tuner Section
Frequency Range 520–1720 kHz
Signal-to-Noise Ratio 45dB
Usable Sensitivity Loop 500μV
$ISTORTION K(Z  -OD 
Selectivity ±10kHz, 30dB
Video Section
Television Format NTSC
Input Level/Impedance 1Vp-p/75 ohms
Output Level/Impedance 1Vp-p/75 ohms
Video Frequency Response
#OMPOSITE AND 36IDEO (Zn-(Z nD"
Video Frequency Response
#OMPONENT 6IDEO (Zn-(Z nD"
($-)
™
Version 1.3a with 10-bit Deep Color
General
Power Requirement AC 120V/60Hz
Power Consumption 65W idle, 540W maximum
(7 channels driven)
Dimensions (Product) (Shipping)
Width 17-5/16 inches (440mm) 21-7/8 inches (555mm)
Height 6-1/2 inches (165mm) 10-1/2 inches (266mm)
Depth 15 inches (382mm) 18-5/16 inches (465mm)
(Product) (Shipping)
Weight 20.5 lb (9.3kg) 25.3 lb (11.5kg)
Depth measurement includes knobs, buttons and terminal connections.
Height measurement includes feet and chassis.
Features, specifications and appearance are subject to change without notice.
Harman Kardon and Logic 7 are trademarks of Harman International Industries, Incorporated,
registered in the United States and/or other countries. EzSet/EQ and Designed to Entertain are
trademarks of Harman International Industries, Incorporated.
Blu-ray Disc is a trademark of the Blu-ray Disc Association.
CEA is a registered trademark of the Consumer Electronics Association.
-ANUFACTURED UNDER LICENSE FROM $OLBY ,ABORATORIES $OLBY THE DOUBLE$ SYMBOL AND 0RO ,OGIC
ARE REGISTERED TRADEMARKS OF $OLBY ,ABORATORIES -,0 ,OSSLESS IS A TRADEMARK OF $OLBY ,ABORATORIES
-ANUFACTURED UNDER LICENSE UNDER 53 0ATENT S    
6,226,616; 6,487,535; 7,003,467 and other U.S. and worldwide patents issued and pending.
DTS, DTS-ES and DTS Neo:6 are registered trademarks, and DTS 96/24, DTS-HD, DTS-HD High
2ESOLUTION !UDIO AND $43($ -ASTER !UDIO ARE TRADEMARKS OF $43 )NC ¥  $43 )NC
All Rights Reserved.
HD-DVD is a trademark of the DVD Format/Logo Licensing Corporation (DVD FLLC).
($-) THE ($-) LOGO AND (IGH$EFINITION -ULTIMEDIA )NTERFACE ARE TRADEMARKS OR REGISTERED
TRADEMARKS OF ($-) ,ICENSING ,,#
iPod is a trademark of Apple Inc., registered in the U.S. and other countries.
SACD is a trademark of Sony Corporation.
TiVo is a registered trademark of TiVo Inc.
Please register your AVR 1600 at www.harmankardon.com.
You’ll need the product’s serial number. At the same time, you can
choose to be notified about new products and/or special promotions.
