Harman Kardon AVR 1600

7
FRONT- PANEL CONTROLS
Digital Input
Navigation
Tuning
Surround Mode
Surround Select
Source Selectors
Headphone Jack/EzSet/EQ Microphone Input
Digital Audio Inputs (Optical 3 and Coaxial 3)
Remote IR Sensor
Video 3 Analog Audio and Video Inputs
USB Port
Tuning Mode
Standby/On Switch
Channel Level Control
Volume
Message DisplaySetPower
Indicator
/
NOTE: To make it easier to follow the instructions throughout the manual that refer to this illustration, a copy of this page may be downloaded from the Product Support section at www.harmankardon.com.
