Harman Kardon AVR 161 User Manual

39
ENGLISH
AVR
Appendix
Table A4 – Source Settings
Cable/
Sat
Disc MHL Radio TV iPod/ USB
Network /
vTuner
Game AUX STB Audio Bluetooth
Connected Device USB N/A
Surround Mode
Video Input N/A N/A N/A N/A N/A
Audio Input Radio HDMI ARC USB Network Bluetooth
Night Mode N/A N/A N/A N/A
Adjust Lip Sync N/A N/A N/A N/A
Change Name N/A N/A N/A N/A N/A
Zone 2 Input N/A N/A N/A N/A
Bass
Treble
Table A5 – HARMAN NSP Settings
Default Settings Your Settings
Stage Width 45
Stage Depth 30
Table A6 – Dolby Pro Logic II Music Settings
Default Settings Your Settings
Center Width 3
Dimension 0
Panorama Off

Harman Kardon AVR 161 Specifications

Audio Section

Stereo power	85W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.1% THD
Multichannel power	85W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.1% THD
Input sensitivity/impedance	250mV/27k ohms
Signal-to-noise ratio (IHF-A)	100dB
Surround-system adjacent channel separation - Dolby Pro Logic/DPLII	40dB
Surround-system adjacent channel separation - Dolby Digital	55dB
Surround-system adjacent channel separation - DTS	55dB
Frequency response (@ 1W)	10Hz – 130kHz (+0dB/–3dB)
High instantaneous current capability (HCC)	±29 amps
Slew rate	40V/sec

FM Tuner Section

Frequency range	87.5MHz – 108.0MHz
Usable sensitivity IHF	1.3µV/13.2dBf
Signal-to-noise ratio (mono/stereo)	70dB/68dB
Distortion (mono/stereo)	0.2%/0.3%
Selectivity (±400kHz)	70dB
Image rejection	80dB
IF rejection	80dB

AM Tuner Section

Frequency range	522kHz – 1, 620kHz
Signal-to-noise ratio	38dB
Usable sensitivity (loop)	425µV
Distortion (1kHz, 50% mod)	1.0%
Selectivity (±10kHz)	30dB

Video Section

Television format	PAL
Input level/impedance	1Vp-p/75 ohms
Output level/impedance	1Vp-p/75 ohms
Video frequency response (composite video)	10Hz – 8MHz (–3dB)
HDMI	Supports up to 4K x 2K

General Specifications

Power requirement	220V – 240V AC / 50Hz – 60Hz
Power consumption	<0.5W (standby); 450W maximum
Dimensions (H x W x D)	121mm x 440mm x 300mm (4-3/4" x 17-5/16" x 11-13/16")
Weight	4.6kg (10 lb)
