AVR 500 Audio/VideoReceiver
OWNER’S MANUAL
AVR 500
CDTAPE DVD VID 1 VID 2 VID 3 6 CH AM/FM PRESET SCAN TUN MODE VMAx
LOGIC 7 C/M
THEATER SURR. OFFPRESETTUNING
Phones
Power
RLMaxMinMaxMin
Bass Treble Balance
Volum
Speaker Multi Room Dig. Select Delay
DIGITAL
PRO LOGIC
3-STEREO
Set
VI
Video
DIGITAL
COAX
Power for the digital revolution.
™
®

Harman Kardon AVR 500 Specifications

Audio Specifications

continuous average power (FTC)	80 Watts per channel, 20Hz–20kHz, @ < 0.07% THD, both channels driven into 8 ohms
power per individual channel (Front L&R channels)	70 Watts per channel, @ < 0.07% THD, 20Hz–20kHz into 8 ohms
power per individual channel (Center channel)	70 Watts, @ < 0.07% THD, 20Hz–20kHz into 8 ohms
power per individual channel (Surround channels)	70 Watts per channel, @ < 0.07% THD, 20Hz–20kHz into 8 ohms
input sensitivity/impedance	200mV/47 kohms
signal-to-noise ratio (IHF-A)	95dB
frequency response	10Hz–100kHz
high instantaneous current capability (HCC)	±45 Amps
rise time	16 µsec
slew rate	40V/µsec

FM Tuner Specifications

frequency range	87.5–108MHz
usable sensitivity IHF	1.3 µV/13.2dBf
signal-to-noise ratio mono/stereo	70/68dB
distortion mono/stereo	0.3/0.3%
stereo separation	40dB @ 1kHz
selectivity	±400kHz, 65dB
image rejection	80dB
IF rejection	90dB
tuner output level	500mV @ 1kHz, ±75kHz Dev

AM Tuner Specifications

frequency range	520–1710kHz
signal-to-noise ratio	45dB
usable sensitivity loop	500µV
distortion	0.8% @ 1kHz, 50% Mod
selectivity	±10kHz, 30dB

Video Specifications

video format	NTSC
input level/impedance	1Vp-p/75 ohms
output level/impedance	1Vp-p/75 ohms
video frequency response	10Hz–8MHz (–3dB)

General Specifications

power requirement	AC 120V/60Hz
power consumption	78W idle, 694W maximum (2 channels driven)
width	17.3 inches (440mm)
height	6.5 inches (165mm)
depth	17.1 inches (435mm)
weight	34 lb (15.4 kg)
