ELECTRICAL PARTS LIST(300Series) DSP P.C. BOARD
REF NO. PART NO. DESCRIPTION REF NO. PART NO. DESCRIPTION
J1320035205X DSP P.C. BOARD
IB
BEADs
J1320035105X DSP P.C. BOARD
BK L 704 J2631200010X HC3550 9.4ohm AXIAL
L 705 J2631200010X HC3550 9.4ohm AXIAL
INTEGRATED CIRCUITs
L 706 J2631200010X HC3550 9.4ohm AXIAL
IC 1 J2142930002X 74VHCT04SJX HEX INVERT L 707 J2631200010X HC3550 9.4ohm AXIAL
IC 2 J2120012001X NJM4558M OP-AMP L 708 J2631200010X HC3550 9.4ohm AXIAL
IC 701 J2120012002X NJM072M OP-AMP L 709 J2631200010X HC3550 9.4ohm AXIAL
IC 702 J2120012002X NJM072M OP-AMP L 821 J2631200010X HC3550 9.4ohm AXIAL
IC 703 J2133926002X CS5360-KS A/D CONVERTER
IC 704 J2142930001X 74VHC153SJX MULTIPLEXER R 6 J2631300174X HB-1T2012-601 CHIP
IC 705 J2129012001X NJU6324M QUARTZ OSC R 7 J2631300174X HB-1T2012-601 CHIP
IC 706 J2136926001X CS8414-CS DIGITAL AUDIO Rx. R 13 J2631300184X HB-1T2012-202 CHIP
IC 707 J2142930003X 74VHCT244SJX OCTAL NON-INVERT R 14 J2631300174X HB-1T2012-601 CHIP
IC 708 J2135326003X CS492604D DECODER R 15 J2631300174X HB-1T2012-601 CHIP
IC 709 J2131003001X KM23C4000DG-8 ROM-0001 R 17 J2631300174X HB-1T2012-601 CHIP
IC 709 J2131328002X AT27C040-100JC ROM OTP R 18 J2631300174X HB-1T2012-601 CHIP
IC 710 J2142930004X 74VHCT574SJX OCTAL D-FILP FLOP R 19 J2631300174X HB-1T2012-601 CHIP
IC 711 J2142930004X 74VHCT574SJX OCTAL D-FILP FLOP R 109 J2631300174X HB-1T2012-601 CHIP
IC 712 J2132321002X HD404354A52H MCU-0002 R 731 J2631300174X HB-1T2012-601 CHIP
IC 712 J2132321001X HD407A435PH SUB-u-COM OTP R 732 J2631300174X HB-1T2012-601 CHIP
IC 713 J2133926003X CS4341-KS D/A CONVERTER R 734 J2631300174X HB-1T2012-601 CHIP
IC 714 J2133926003X CS4341-KS D/A CONVERTER R 755 J2631300174X HB-1T2012-601 CHIP
IC 715 J2133926003X CS4341-KS D/A CONVERTER R 756 J2631300174X HB-1T2012-601 CHIP
IC 716 J2120012002X NJM072M OP-AMP R 760 J2631300174X HB-1T2012-601 CHIP
IC 717 J2120012002X NJM072M OP-AMP R 767 J2631300174X HB-1T2012-601 CHIP
IC 718 J2120012002X NJM072M OP-AMP R 781 J2631300174X HB-1T2012-601 CHIP
IC 719 J2142930006X 74VHCU04MX HEX INVERT R 782 J2631300174X HB-1T2012-601 CHIP
IC 720 J2112504001X BA033T REGULATOR 3.3V R 785 J2631300174X HB-1T2012-601 CHIP
IC 722 J2120012001X NJM4558M OP-AMP R 799 J2631300174X HB-1T2012-601 CHIP
IC 723 J2120012001X NJM4558M OP-AMP R 800 J2631300174X HB-1T2012-601 CHIP
IC 724 J2120012001X NJM4558M OP-AMP R 817 J2631300174X HB-1T2012-601 CHIP
IC 725 J2120012001X NJM4558M OP-AMP R 818 J2631300174X HB-1T2012-601 CHIP
R 839 J2631300174X HB-1T2012-601 CHIP
TRANSISTORs
R 840 J2631300174X HB-1T2012-601 CHIP
Q 703 J2021000201X KTA1266-Y PNP R 853 J2631300174X HB-1T2012-601 CHIP
Q 704 J2021220101X KRC101M NPN R 854 J2631300174X HB-1T2012-601 CHIP
Q 705 J2021200101X KRA101M PNP R 869 J2631300174X HB-1T2012-601 CHIP
Q 706 J2021060001X KTD1302-B NPN R 870 J2631300174X HB-1T2012-601 CHIP
Q 707 J2021060001X KTD1302-B NPN
Q 708 J2021220101X KRC101M NPN
RESISTORs
Q 709 J2021200101X KRA101M PNP R 822 J3013561320X 1/5W CARBON 560W-J
Q 710 J2021060001X KTD1302-B NPN
Q 711 J2021060001X KTD1302-B NPN R 1 J3024101120X 1/10W CHIP 100W-J
Q 712 J2021220101X KRC101M NPN R 2 J3024222120X 1/10W CHIP 2K2W-J
Q 713 J2021200101X KRA101M PNP R 3 J3024473120X 1/10W CHIP 47KW-J
Q 714 J2021060001X KTD1302-B NPN R 4 J3024473120X 1/10W CHIP 47KW-J
Q 715 J2021060001X KTD1302-B NPN R 5 J3024222120X 1/10W CHIP 2K2W-J
Q 716 J2021220301X KRC103M NPN R 8 J3024472120X 1/10W CHIP 4K7W-J
R 9 J3024472120X 1/10W CHIP 4K7W-J
DIODEs
R 10 J3024101120X 1/10W CHIP 100W-J
D 705 J2221010100X 1SS133 SW. R 11 J3024474120X 1/10W CHIP 470KW-J
D 706 J2221010100X 1SS133 SW. R 12 J3024474120X 1/10W CHIP 470KW-J
R 701 J3024203120X 1/10W CHIP 20KW-J
COILs
R 702 J3024203120X 1/10W CHIP 20KW-J
L 701 J2616247020X AXIAL LAL02 47uH-K R 703 J3024103120X 1/10W CHIP 10KW-J
L 702 J2616247020X AXIAL LAL02 47uH-K R 704 J3024103120X 1/10W CHIP 10KW-J
L 703
J2616247020X AXIAL LAL02 47uH-K R 705 J3024103120X 1/10W CHIP 10KW-J
-30
