REF NO. PART NO. DESCRIPTION REF NO. PART NO. DESCRIPTION
C 901 J3514220270X
CERA/AX CH 50V 22pF-J
SW 904 J46500500002 SKHV10910A 2P TACT SW.
C 902 J3514220270X
CERA/AX CH 50V 22pF-J
SW 905 J46500500002 SKHV10910A 2P TACT SW.
C 903 J3524104540X
CERA/AX
F 25V 0.1uF-Z SW 906 J46500500002 SKHV10910A 2P TACT SW.
C 905 J3524104540X
CERA/AX
F 25V 0.1uF-Z SW 907 J46500500002 SKHV10910A 2P TACT SW.
C 907 J3524104540X
CERA/AX
F 25V 0.1uF-Z SW 908 J46500500002 SKHV10910A 2P TACT SW.
C 908 J3524471170X
CERA/AX B 50V 470pF-K
SW 909 J46500500002 SKHV10910A 2P TACT SW.
C 909 J3524104540X
CERA/AX
F 25V 0.1uF-Z SW 910 J46500500002 SKHV10910A 2P TACT SW.
C 910 J3524102170X
CERA/AX B 50V 1000pF-K
SW 911 J46500500002 SKHV10910A 2P TACT SW.
C 911 J3524102170X
CERA/AX B 50V 1000pF-K
SW 912 J46500500002 SKHV10910A 2P TACT SW.
C 912 J3524102170X
CERA/AX B 50V 1000pF-K
SW 913 J46500500002 SKHV10910A 2P TACT SW.
C 913 J3524102170X
CERA/AX B 50V 1000pF-K
SW 914 J46500500002 SKHV10910A 2P TACT SW.
C 914 J3524104540X
CERA/AX
F 25V 0.1uF-Z SW 915 J46500500002 SKHV10910A 2P TACT SW.
C 915 J3524104540X
CERA/AX
F 25V 0.1uF-Z SW 916 J46500500002 SKHV10910A 2P TACT SW.
C 918 J3524104540X
CERA/AX
F 25V 0.1uF-Z SW 917 J46500500002 SKHV10910A 2P TACT SW.
C 919 J3514121270X
CERA/AX CH 50V 120pF-K
SW 918 J46500500002 SKHV10910A 2P TACT SW.
C 920 J3514121270X
CERA/AX CH 50V 120pF-K
SW 919 J46500500002 SKHV10910A 2P TACT SW.
C 922 J3524104540X
CERA/AX
F 25V 0.1uF-Z SW 920 J46500500002 SKHV10910A 2P TACT SW.
C 954 J3514101270X
CERA/AX CH 50V 100pF-K
SW 921 J46500500002 SKHV10910A 2P TACT SW.
C 973 J3524104540X
CERA/AX
F 25V 0.1uF-Z SW 922 J46500500002 SKHV10910A 2P TACT SW.
C 974 J3524152730X
CERA/AX
X 16V 1500pF-M BK SW 923 J46500500002 SKHV10910A 2P TACT SW.
C 974 J3524472730X
CERA/AX
X 16V 4700pF-M IB SW 924 J46500500002 SKHV10910A 2P TACT SW.
C 975 J3524152730X
CERA/AX
X 16V 1500pF-M BK SW 925 J46500500002 SKHV10910A 2P TACT SW.
C 975 J3524472730X
CERA/AX
X 16V 4700pF-M IB SW 926 J46500500002 SKHV10910A 2P TACT SW.
C 979 J3524104540X
CERA/AX
F 25V 0.1uF-Z SW 927 J46500500002 SKHV10910A 2P TACT SW.
C 980 J3524104540X
CERA/AX
F 25V 0.1uF-Z SW 928 J46500500002 SKHV10910A 2P TACT SW.
SW 929 J46500500002 SKHV10910A 2P TACT SW.
C 947 J3515470270X
CERA/CHIP
CH 50V 47pF-J
SW 930 J46500500002 SKHV10910A 2P TACT SW.
C 948 J3515470270X
CERA/CHIP
CH 50V 47pF-J
SW 933 J46500500002 SKHV10910A 2P TACT SW.
VR 901 J32612050102 EC16B24D0002ZZZ ENCODER VR.
C 937 J3600223238X
FOIL POLY/RA 100V 0.022uF-J
X 901 J3913010035X
9.8304MHz 22pF X-TAL
C 938 J3600223238X
FOIL POLY/RA 100V 0.022uF-J
J60610501000 CASE,SHIELD(F);SPTE O.3
C 939 J3600223238X
FOIL POLY/RA 100V 0.022uF-J
J97200505000 CUSHION-FLT;SPONGE 25
C 940 J3600223238X
FOIL POLY/RA 100V 0.022uF-J
C 943 J3600182238X
FOIL POLY/RA 100V 1800pF-J
HEAD PHONE P.C. BOARD
C 944 J3600182238X
FOIL POLY/RA 100V 1800pF-J
JP 961 J4432210120X
HTJ-064-07BGGOLD 1P H/P JACK
CN 901 J43344054141 5P,1007#26/2547#26,410m/m
C 906 J4433210421X
SCDA5R5104H 5.5V 0.1F
CN 904 J43244021041 2P,1007#26,STRAIGHT,100m/m
C 969 J3524104540X
CERA/AX
F 25V 0.1uF-Z
WAFERs
C 970 J3524104540X
CERA/AX
F 25V 0.1uF-Z
CN 923 J4422113020X
8370-307 30P 1.25mm
CN 924 J4422112220X
8370-227 22P 1.25mm
MAIN SW. P.C. BOARD
WA 903 J4420040200X 5267-02A 2P 2.5mm
!
SW932 J46205050108
SY-16-32-2(U99S2)/T
TV5
POWER SW.
WA 904 J4420040200X 5267-02A 2P 2.5mm
!
C 968 J3531472412X
SPARK-KILLER AC250V
0.0047uF-M
!
CN 983 J4420060200X 35328-0210 2P 7.92mm
WIREs
CN 907 J43344084341 8P,1007/2547#26*2C,430m/m
STAND-BY SW. P.C. BOARD
CN 911 J43344062641 6P,1533#26,260m/m SW 931 J46500500002 SKHV10910A 2P TACT SW.
CN 986 J43244244331 7P,1007#24,430m/m LED 901 J2332301011X
SPR-54MVWRED/GREEN LED
T 901 J43199011529 1P,1007#22,150m/m CN 903 J43254021041 2P,1007#26,100m/m,ANGLE
T 902 J43199011529 1P,1007#22,150m/m CN 987 J43244034531 3P,1007#24,450m/m
T 903 J43199011529 1P,1007#22,150m/m
T 904 J43199011529 1P,1007#22,150m/m
!
J43217025001 2P,1672#18,500m/m CN983<->SUB
J4112223201X
FFC 320mm 1.25mm 22P
TO DSP
J4112302801X FFC 280mm 1.25mm 30P
TO MAIN
MISCELLANIES
FLT 901 J2352220011X
CM1906C VFD
JP 901 J4430130110X
JK0300081G Y/W/R 3P RCA JACK
RMT 901 J2411320014X RPM6938-H4 38kHz RMC SENSOR
SW 901 J46500500002 SKHV10910A 2P TACT SW.
SW 902 J46500500002 SKHV10910A 2P TACT SW.
SW 903 J46500500002 SKHV10910A 2P TACT SW.
-51
