Rear Panel Connections
11
ª Phono Inputs: Connect the out-
puts of your turntable or tone arm to
these jacks. Note that only Moving
Magnet (MM) type cartridges may
be used.
‚ Phono Ground: Connect the
ground wire from a turntable to this
terminal to reduce system hum.
⁄ TV Monitor Video Output:
Connect this jack to the standard
(composite) video input of a TV
monitor or video projector to view
the output of any standard video
source selected by the receiver’s
video switcher.
Speaker Terminals: Connect
these terminals to the appropriate
terminals on your speakers.
‹ Switched AC Outlets: These out-
lets may be used to power any
device that you wish to have turn on
when the unit is turned on with the
System Power Control switch 2.
NOTE: The power consumption of
the device plugged into each of
these outlets should not exceed
100 watts.
› Power Cable: Connect the AC
plug to a non-switched AC wall
output
fi Video 2 Inputs: Connect these
jacks to the audio and video outputs
of a TV Tuner, Cable TV converter
box, satellite receiver or any other
audio/video source.
fl Video 1 Inputs: Connect these
jacks to the audio and video
PLAY/OUT jacks of a VCR.
‡ Video Outputs 1: Connect these
jacks to the audio and video
RECORD/IN jacks of a VCR.
° 6-Channel Direct Inputs: If an
external digital audio decoder is
used for 5.1 (Dolby Digital, DTS,
etc.) audio, connect the outputs of
that decoder to these terminals.
· AM Antenna: Connect the AM
loop antenna supplied with the
receiver to these terminals. If an
external AM antenna is used, make
connections to the AM and GND
terminals in accordance with the
instructions supplied with the
antenna.
a FM Antenna: Connect an indoor
or external FM antenna to this
terminal.
