This manual provides instructions for proper
installation of this Curved Stair Lift. Please
refer to the Owner’s Manual for operating
instructions. Be sure to provide the Owner’s Manual
to the owner of the lift before it is put into service.
Any alterations to the equipment without written
authorization by the manufacturer may void the
warranty.
Our lifts are designed to install with as little
assembly as possible. If you have questions,
concerns or comments, please contact Harmar’s
Technical Service Department at 1-866-378-6848 or
email tech@harmar.com.
Device Name: Harmar Helix Curved Stair Lift
Indications for Use: The intended use of the Helix
Stair Lift is to assist transfers of patients or mobility
impaired persons up and down ights of stairs.
SYMBOLS USED IN THIS MANUAL
READ MANUAL - Pay close attention to
the instructions in the manual.
CAUTION - Hazardous situation. If not
avoided, could result in serious damage
to property.
WARNING - Hazardous situation. If not
avoided, could result in serious injury
to installer or user.
HEAVY - Be sure to have help available
to avoid back injury.
TIP - Helpful tips that will facilitate ease
of installation.
CHECK - Reminder to check certain
portions of installation before
continuing.
Lifts shall be installed so that means of egress is
maintained as required by the authority having
jurisdiction. 7.1.1
The structure which equipment is installed shall be
capable of supporting the loads imposed. 7.1.2
The installation of electrical equipment and wiring
shall conform to the requirements of NFPA70 7.6.4
Foot Rest Clearance. At no point in its travel shall
the edge of the footrest facing the upper landing
be more than 24 inches (610 mm) above the step or
landing as measured vertically.
ASME A18.1-2014 "SAFETY STANDARD FOR
PLATFORM LIFTS AND STAIRWAY CHAIR LIFTS"
CONTENTS
TABLE OF CONTENTS 2
WHATS IN THE BOX 3
REQUIRED TOOLS 4
INSTALLATION 5-13
FINAL CHECKS 14
TECHNIAL SPECIFICATIONS 15
WIRING 16
MAINTENANCE 17-18
