Vantage Stair Lift
INSTALLING THE RAIL
2. Position the two ends of the rails close together. Connect the plugs on each end of the two power supply
wires inside the rail pieces. [Figure 14-1 and 14-2]
Figure 14-1
Figure 14-2
CAUTION
Be careful not to pinch wires when
sliding rails together.
Figure 14-3
3. Tuck the wire back into the rail channel.
4. Slide the rail onto the splice bars and tighten all
splice bar screws. [Figure 14-3]
SPLICE BAR CHANNELS
To Next Page
