Harmar Mobility Vantage SL400 - MANUAL LOWERING TOOL USAGE; Manual Lowering Procedure

TEC0017 23Jan2015 P/N: 630-00027-01 revC
SL400 • Vantage Stair Lift Installation Manual
33
Vantage Stair Lift
MANUAL LOWERING TOOL
1. Turn the lift o at the power switch.
NOTE: Disconnecting the power supply does not
turn the lift o. The power supply only charges
the batteries.
2. Remove the round plastic plug on the end of the
chassis to access the end of the motor shaft.
[Figure 32-1]
3. Place the manual lowering tool onto the end of
the motor shaft and rotate until the nal limit switch
becomes disengaged.
4. Re-install the plastic plug and turn the lift "ON".
MANUAL LOWERING TOOL
CAUTION
If the lift is inoperable because it has driven onto the nal limit switch or has run out of
power, it has to be manually moved off the nal limit
