Harmar Mobility Vantage SL400 - Whats in the Box

TEC0017 23Jan2015 P/N: 630-00027-01 revC
SL400 • Vantage Stair Lift Installation Manual
5
Vantage Stair Lift
PREPARATION - WHAT'S IN THE BOX
WHAT’S IN THE BOX
Box 1
1. q Stair Lift Chassis (1)
2. q Remote Controls with Batteries (2)
3. q Installation Manual (1)
4. q Owner's Manual / Warranty (1)
5. q Rail Mounting Brackets (2 per rail)
6. q Lag Bolts (6 per rail)
7. q Power Supply (1)
8. q Power Cord (1)
9. q Limit Cams (2)
10. q Limit Cam bolts and square nuts (4)
11. q 7 mm Manual Lowering Device (1)
12. q Timing Gear Rack (1)
13. q 9/64" Hex Wrench (1)
14. q End Stop (1)
15. q Christmas Tree Plugs (2)
16. q Face Plate (1)
17. q Tube of Lubricant (1)
Box 2
18. q Seat Assembly (1)
19. q Rooster Post (1)
Box 3 (not shown)
20. q 2 Alumium Rails - Installations over 16 feet will
be shipped with 3 or 4 rails, depending on installation
requirements
21. q 2 Splice Bars - Installations over 16 feet will
be shipped with 4 or 6 splice bars, depending on
installation requirements (Installed on rails)
22. q 2 Rail End Covers (Installed on rails)
23. q 2 Charging Stations (Installed on rails)
24. q Gear Rack (Installed on rail)
1
12
5
17
18
15
16
14
13
11
10
9
8
7
6
4
3
2
19
