Harmar Mobility VPL400-X - Vertical Platform Lift Components; External Lift Elements

VPL400-X: Owner’s Manual
05MAY23 | 610-00103 A
6
INTRODUCTION
HIGHLANDER 400-X: SECTION 2
KEY VERTICAL PLATFORM
LIFT ELEMENTS
1. Top Cap
2. Decal
3. Data Serial Tag
4. Platform
5. Platform Guard Panel
6. Grab Rail (if supplied)
7. Platform Controls
8. Platform Safety Pan
9. Platform Folding Ramp/
Platform Fixed Ramp
10. Tower
11. Folding Ramp Actuator Tube
1
2
10
11
3
7
5
6
8
4
9
