Harmar Mobility VPL400-X - Internal Lift Elements

VPL400-X: Owner’s Manual
05MAY23 | 610-00103 A
7
INTRODUCTION
HIGHLANDER 400-X: SECTION 2
KEY INTERNAL VERTICAL
PLATFORM LIFT ELEMENTS
1. Manual Lowering Tool
2. Motor / Gearbox
3. ACME Screw with Drive and Safety nuts
4. Control Electronics Assembly
5. Tower Frame
6. Tower Legs
7. Wire Channel
8. Over-Speed Safety Assembly
9. Motor Contactors
10. Carriage
11. Trailing Cable
12. Cable Tensioning Pulley
13. Junction Box
(Main Power Supply Hookup)
1
10
2
7
9
8
11
11
5
4
3
13
6
12
