4-7-3 Movable range for each limit switch
The mechanical limit switches have limits for the movable range of the actuator as follows:
Movable range for limit switch 1 Moveable range for limit switch 2
Moveable range
Actuating position Actuating position
Movable range for limit switch 1 Moveable range for limit switch 2
Moveable range
Actuating position Actuating position
Moveable range
40
Chapter 4 Options
!
CAUTION
Do not overrun beyond the moveable range mentioned above.
The over running may damage the limit switch resulting mechanical failure and physical injury.
