Fig. 2: View from the left
1 Device lid 14 Compressed-air connector
3 4 x M5 hexagonal socket screws 15 Screws for injector mounting
4 Front lid 16 Knurled nut for slide-in sieve
10 Air outlet 17 Socket for foot switches
13 Mains socket (230 V /50 Hz)
