Harris Micromax FM Exciter System Overview REV1 01/12/2007
1-7
WARNING: Disconnect primary power prior to servicing
MAIN CARD
CONTROLLER
30W RF PA
POWER SUPPLY
FIGURE 1-4
Location of Subsystems
