3-2
WARNING: Disconnect primary power prior to servicing
Harris Micromax FM Exciter Operation REV1 01/12/2007
3.3 Adjusting RF power output
In default mode, front LCD screen displays forward power output and modulation level as follows:
To adjust power, press the KNOB for approximately 2 seconds until the display changes to SET
mode as shown below. When the display changes to the SET menu, release the KNOB. Then turn the knob
to raise and lower the RF output power to desired level.
