Harris Micromax FM Exciter Operation REV1 01/12/2007
3-7
WARNING: Disconnect primary power prior to servicing
How to remotely program operating frequency and RF power level using Windows
Hyperterminal
1) Turn Exciter on into proper load
2) Open up Windows Hyperterminal on the computer
3) Select Connect using COMx (your serial or RS-232 port)
4) Select BPS: 19200 (2400/4800/9600 will also work), Data Bits: 8, Parity: None, Stop
Bits: 1
Flow Control: none (without handshake)
5) Connect computer comport to RS232 port on exciter
6) FOR FREQ enter FR*98.000 (enter freq in format xxx.xxx)
FOR POWER LEVEL enter PWR075% (100% = 30 Watts)
7) If it is received correctly, the exciter will give an echo to the computer.
Attachment 1
