Harris ZX5000 User Manual

7-2 888-2595-001 12/20/11
WARNING: Disconnect primary power prior to servicing.
Section 7 Parts List
ZX Series
7.1 ZX5000 Replaceable Parts List
Table 7-1 XMTR, ZX5000 CONFIG - 995 0035 009 (A)
Harris PN Description Qty UM Ref Des
817 2311 030 DWG, FAMILY TREE, ZX5000 0 DWG
952 9232 034 KIT, ZXB STANDALONE 0 EA
952 9232 035 EXC INTERFACE CABLE KIT, ZXB TO FLEXSTAR HD 0 EA
952 9232 036 EXC INTERFACE CABLE KIT, ZXB TO DIGIT/MICROMAX/FM ONLY0 EA
9710027006G FLEXSTAR BOOST AMP 0 EA
981 0090 006 ASSY, AMPLIFIER, ZX 5000 1 EA
981 0090 059 ASSY, KIT, BLANK AC MAINS CONNECTORS (POWERCON 20A)1 EA
990 1202 002 KIT, MODULE SPARES, ZXB 0 EA
990 1204 001 KIT, BOARD SPARES, ZX5000 0 EA
990 1261 001 KIT, BASIC, SPARE PARTS, ZXB 0 EA
994 9410 005 ! EXCITER, DIGIT CD 0 EA
995 0013 056 FLEXSTAR FM EXCITER (5/6 ROHS) 0 EA
HARMICROMAXANALOGMICROMAX EXCITER ANALOG AUDIO 0 EA
HARMICROMAXDIGITALMICROMAX EXCITER DIGITAL AUDIO 0 EA
Table 7-2 KIT, ZXB STANDALONE - 952 9232 034 (A)
Harris PN Description Qty UM Ref Des
408 0212 000 BACKSHELL, D-SUB 15C NO-SHIELD 1 EA
408 0216 000 BACKSHELL, D-SUB 25C NO-SHIELD 1 EA
610 1212 000 PLUG, D 15C STRAIGHT SLDRCUP 1 EA
610 1346 000 PLUG, D, 25 PIN, SOLDER CUP 1 EA
Table 7-3 EXC INTERFACE CABLE KIT, ZXB TO FLEXSTAR HD - 952 9232 035 (A)
Harris PN Description Qty UM Ref Des
256 0246 005 CABLE, DB15M/DB15M 5FT 1 EA
556 0136 000 ATTEN, SMA, 20DB, 0.5W, 50 OHM 1 EA
943 5567 239 ASSY, RF SAMPLE SPLITTER 1 EA
952 9232 033 EXC INTERFACE CABLES, ZXB TO FLEXSTAR (HD & RTAC) 1 EA
Table 7-4 EXC INTR CABLE KIT, ZXB TO DIGIT/MICROMAX/FM ONLY - 952 9232 036 (B)
Harris PN Description Qty UM Ref Des
952 9232 032 EXC INTERFACE CABLES, ZXB TO DIGIT/MICROMAX/FM ONLY1 EA
Table 7-5 FLEXSTAR BOOST AMP - 9710027006G (B)
Harris PN Description Qty UM Ref Des
250 0628 000 CABLE/ASSY, USB-A, BULKHEAD 0.5 EA J4
250 0671 000 CORD, AC, 3C, NEMA/IEC PLUG RT ANGLE 1 EA
346 0711 000 CARD GUIDE, 6LG, GROUNDED 2 EA
358 3197 000 SLIDES 10 PAIR 1 PR
396 0261 000 DISPLAY, LCD BLUE 1 EA
398 0552 000 FUSE, CART 5X20MM 10A SLOW 2 EA FL1F1 FL1F2
424 0012 000 GROMMET 0.250 GROOVE DIA 1 EA
430 0192 000 FAN GUARD, 120MM WIRE-FORM 1 EA
430 0313 000 FAN, 12V 110CFM 119MM SQ 1 EA B1
430 0321 000 FILTER ASSY, AIR 120MM FAN 1 EA
544 1704 000 TERM, 50-OHM SMB 1GHZ 1 EA R1
