HARTING Han M23 - Page 10

51
10
09 15 100 0363
1)
09 15 100 0373
1)
09 15 100 0364
1)
09 15 100 0374
1)
Bulkhead mounted housing,
front wall assembly,
for male insert (M20 x 1.5)
Bulkhead mounted housing,
front wall assembly,
for female insert (M20 x 1.5)
Bulkhead mounted housing,
front wall assembly,
for male insert (PG 13.5)
Drawing
Identification Part number Dimensions, in mm
Panel cut out Ø 20
Panel cut out Ø 20
Panel cut out Ø PG 13.5
1)
Not suitable for rapid locking
Bulkhead mounted housing,
front wall assembly,
for female insert (PG 13.5)
Panel cut out Ø PG 13.5
Han
®
M23 Signal Bulkhead mounted housing
