HARTING Han M23 - Page 17

51
17
17 09 15 117 3001 09 15 117 3101
17 09 15 117 2602 09 15 117 2702
17 09 15 117 2603 09 15 117 2703
Crimp termination;
17 x 1 mm contacts
Solder termination
PCB solder-in termination
1)
Contact Part number Drawing
Identification number Male insert Female insert Dimensions, in mm
Male Female
1)
Only for use with bulkhead mounted housings: 09 15 100 0301, 09 15 100 0302, 09 15 100 0305, 09 15 100 0306 and 09 15 100 0307
Han
®
M23 Signal Inserts
