HARTING Han M23 - Page 18

51
18
19 09 15 119 3001 09 15 119 3101
19 09 15 119 2602 09 15 119 2702
19 09 15 119 2603 09 15 119 2703
Crimp termination;
16 x 1 mm contacts
3 x 1.5 mm contacts
Solder termination
PCB solder-in termination
1)
Contact Part number Drawing
Identification number Male insert Female insert Dimensions, in mm
Male Female
1)
Only for use with bulkhead mounted housings: 09 15 100 0301, 09 15 100 0302, 09 15 100 0305, 09 15 100 0306 and 09 15 100 0307
Han
®
M23 Signal Inserts
