51
26
①
max. 25 mm
②
4 mm
③
④
⑤
⑥
⑦
✂
⑧
Female Male
Han
®
M23 Signal, hood, cable to cable / panel feed-through housing
Crimping*
Coding
* Refer to the operating instructions for the crimping tool
09 99 000 0890 or 09 99 000 0896.
Click!
Click!
A/F 24
A/F 24
Han
®
M23 Signal Assembly instructions
