HARTING Han M23 - Page 27

51
27
60 mm
①
②
4 mm
③
④
⑤
⑥
⑦
⑧
⑨
⑩
✂
⑪
⑫
***
Click!
Han
®
M23 Signal hood, angled, EMC & EMC rotatable
* Han
®
M23 hood, angled,
7-12 mm
** Han
®
M23 hood, angled,
7-12 mm, rotatable
* Han
®
M23 hood, angled, 7-12 mm
** Han
®
M23 hood, angled, 7-12 mm,
rotatable
Code
Click!
Click!
A/F 24*/27**
A/F 24* / 25**
A/F 24
*** Cut the shielding
to a length
designated by
the scissors!
Han
®
M23 Signal Assembly instructions
