HARTING Han M23 - Page 45

51
45
①
③
⑤
⑥
⑦
Stripping length X
1 mm contacts: x = 4 mm
2 mm contacts: x = 7 mm
X
②
④
✂
max. 37 mm
⑧
✔
Do not touch the white clip!
**
A/F 24
A/F 24
* Refer to operating instructions of crimping tool 09 99 000 0896.
** Cut the shielding to a length designated by the scissors.
Han
®
M23 Power, hood 4+3+PE / 5+3+PE
Crimping*
Click!
2 x Click!
Click!
Click!
Han
®
M23 Power / Hybrid Assembly instructions
